Features

•

Receives two audio channels from a Dante

quality digital audio can be routed from the Dante network and converted to balanced

or unbalanced line level analog audio on a captive screw connector.

Mirrored two-channel analog and S/PDIF audio outputs — Audio is provided as

two line level analog outputs on captive screw connectors and a mirrored two-channel

S/PDIF output on a coaxial RCA connector.

Studio grade 24-bit digital-to-analog conversion with selectable sampling rates

up to 96 kHz — Professional converters fully preserve the integrity of the original audio

signal with selectable sampling rates via Dante Controller.

Power over Ethernet — Allows the AXI 02 AT to receive power and audio over a

single Ethernet cable, eliminating the need for a local power supply.

1U, eighth rack width enclosure, ZipClip™ 100 included — Compatible with

Extron Rack Shelves and ZipClip mounting solutions.

Software adjustable analog output attenuation — Compensates for downstream

level requirements using SIS commands via USB or DSP Configurator.

Dante audio networking provides a wide range of expansion capabilities —

Dante-equipped audio products, including the AXI 02 AT, provide scalability for creating

larger audio systems over a local area network using standard network protocols and

hardware.

network — Two channels of high

AXI 02 AT • Introduction
