UNIVERSAL TOASTER UTX-200L
INSTALLATION (continued)
Bun Feeder
Release Sheet
Retainer Bar
Breakfast
Chute
Platen
Release Sheet
Unit Crumb
Bun Buffer
Tray
Power
Cord
NOTE: To access the
Control Panel, open the
front cover. This
reveals the full
I/R
The Breakfast Chute
Control Panel (Inset). PLTN
should be installed MOTOR
as shown.
ADJUST PRGM PREV NEXT SELECT
UT
BREAKFAST/LUNCH
NOTE: When installing the Release Sheet, make
sure it is not caught in the conveyor. Additional
Release Sheets can be obtained through your
Authorized Service Agency.
Figure 1. Universal Toaster Components
P/N 1010992 Rev. K 03/15
