UNIVERSAL TOASTER UTX-200L

Adjusting the Upper and Lower I.R.

If toasted muffins and/or bagels are too light and the
toasting quality is at the darkest setting, you may need
to increase the Upper and Lower I.R. percentages from
their default settings.
NOTE: The Muffin and Bagel modes must always
have the same Upper and Lower I.R. settings.
1. While in Muffin Ready mode, open the Front
Cover and press and hold the PRGM button for 3
seconds to go into Program mode.
NOTE: The unit will exit Program mode after 10
seconds of inactivity.
2. The following appears on the display:
Program Muffin
Press Select
3. Press the SELECT button and then press the
NEXT button once to display the Upper I.R. set-
ting. It should read 80%.
4. Press the SELECT button once to go into Edit
mode. The value should start blinking.
5. Press the NEXT button twice to increase the
Upper I.R. setting to 84%.
6. Press the SELECT button to store the new Upper
I.R. setting.
7. Press the NEXT button once to display the Lower
I.R. setting. It should read 50%.
8. Press the SELECT button once to go into Edit
mode. The value should start blinking.
9. Press the NEXT button twice to increase the
Lower I.R. setting to 54%.
10. Press the SELECT button to store the new Lower
I.R. setting.
11. Press the PRGM button to exit Program mode.
12. Press the Bagel Selector button on the rear of the
toaster to select Bagel mode.
13. While in Bagel Ready mode, press and hold the
PRGM button for 3 seconds to go into Program
mode.
14. The following appears on the display:
Program Bagel
Press Select
15. Repeat steps 3 through 11 to adjust the Upper
I.R. setting to 84% and the Lower I.R. setting to
54%.
OPERATION (continued)
16. Once outside of Program mode, press the
17. Use the PREV and NEXT buttons to bring the
NOTE: Two bars will be lit when the adjustment is in
the center (Figure 7).
18. Press the PRGM button when the adjustment is
19. Close the Front Cover and allow the unit to warm
20. Test one or two muffins and bagels to ensure the
21. If these settings do not give the desired results,
NOTE: If the unit is reset to the factory default,
these new Upper and Lower I.R. settings will need
to be re-entered.
14
ADJUST button (Figure 7).
toasting quality indicator into the center of the
range (Figure 7).
I/R
Light Buns
PLTN
MOTOR
ADJUST
PRGM PREV
UT
BREAKFAST/LUNCH
Figure 7. Adjusting Toasting Quality
complete to return to Ready mode.
up for 10 to 20 minutes.
product is toasting with the desired quality.
you may use the same steps to increase or
decrease the Upper and Lower I.R. settings, or
you may use the ADJUST button to make the
toasting quality lighter or darker.
Dark
NEXT SELECT
