UNIVERSAL TOASTER UTX-200L
Problem
Unit displays the following message:
Platen Fail
NOTE: A Thermocouple which has
become grounded will cause erratic
controller behavior.
Unit displays the following message:
Platen SSR Fail
The overtemp thermocouple tempera-
ture is greater than 250ºF (121
less than 350ºF (177 . Unit
°C)
displays the following message:
Main Blower Fault
The overtemp thermocouple tempera-
ture is greater than 350ºF or an open
thermocouple condition exists. Unit
displays the following message:
IR Sensor Fail
Cooling fan speed error. Unit displays
one or more of the following mes-
sages:
Left Fan Fault
Ctrl Hsg Fan Fault
Right Fan Fault
Product sticking in vertical conveyor
or product not toasted properly.
Unit displays the following message:
WARNING! Power Fault
Unplug now!!!
TROUBLESHOOTING
Possible Cause
The Thermocouple in the Platen
circuit has failed.
A control relay has a short or the
Thermocouple is not pushed into
Platen correctly.
There is a problem with the main
but convection blower.
°C)
There is a problem with the main
convection blower.
Cooling fan failure.
Dirty Release Sheet.
Bun Thickness Compression
Control knob is set incorrectly.
Product inserted incorrectly into
vertical conveyor.
Unit may not be in the proper oper-
ation mode.
Contactor and control relay failures.
Unit has detected IR current or
rising Platen temperature with the
power off.
The toaster cannot be operated in
Lunch mode with this type of failure.
Contact your Authorized Service
Agency for service.
The toaster will open the C1 contac-
tor, disabling the toaster. Contact
your Authorized Service Agency for
service.
Unit will operate normally but this
issue should be addressed by an
Authorized Service Agency.
The toaster will shut down. Allow
the toaster to cool and the restart. If
this condition persists, contact your
Authorized Service Agency for
service.
The toaster will operate normally
until the compartment ambient tem-
perature exceeds 150ºF (66
this point the toaster will shut down.
Contact your Authorized Service
Agency for service.
Clean the Release Sheet according
to the Maintenance section of this
manual.
Set the Bun Thickness Compression
Control knob is set to 3.
Refer to the Operation section in this
manual for proper operation proce-
dures. Also refer to the product labels
on the unit.
When toasting Muffins or Bagels,
the unit must be in Breakfast Mode.
When toasting Buns, the unit must
be in Lunch Mode. Refer to the
Operation section of this manual.
Immediately unplug the power cord
and call your Authorized Service
Agency for service. The unit must not
be operated with this kind of failure.
18
Corrective Action
. At
°C)
