5.2.8. ELECTRIC HEATER

This option allows you to check electric heater.
It is necessary to press the ''START'' next to the corresponding symbol and check if the electric
heater is working. After pressing the'' STOP'' electric heater will stop working. Each time you press''
'START'' it becomes ''STOP'' and vice versa. The display will show animation of the electric heater
when the option is active. In this option, when the electric heater is working, then also and fan
is working (fan symbol rotates when the option is active).
5.2.9. VALVE CLOSING
This option allows you to check the motor device of 4-way mixing valve.
It is necessary to press the ''START'' next to the corresponding symbol and check if the motor device
of 4-way mixing valve is working. Motor device should close the 4-way mixing valve. After pressing
the ''STOP'' motor device will stop working. Each time you press ''START'' it becomes ''STOP'' and
vice versa. The display will show the symbol of (closing) motor device when the option is active.
5.2.10. VALVE OPENING
This option allows you to check the motor device of 4-way mixing valve.
It is necessary to press the ''START'' next to the corresponding symbol and check if the motor device
of 4-way mixing valve is working. Motor device should open the 4-way mixing valve. After pressing
the'' STOP'' motor device will stop working. Each time you press ''START'' it becomes ''STOP'' and
vice versa. The display will show the symbol of (opening) motor device when the option is active.
5.2.11. ALARM
This option allows you to check the work of sound/light alarm CAL (not included in delivery).
It is necessary to press the '' START '' next to the corresponding symbol and make sure that it works
properly. It can be particularly checked for errors and fuel level.
Technical instructions REGULATION PelTec / PelTec-lambda
Manual test
53
