Centrometal PelTec 12-48 Technical Instructions page 55

The factory set temperature that must be achieved to start measuring (except for conditions that
can be changed - boiler power and time).
5.3.2 TIME
Possible selection:
Factory: 600 sec
Minimum: 600 sec
Maximum: 3600 sec
After the set parameters are met there is min. time to stabilize the flame before measuring. This
time begins to run when the boiler is on selected power Dx and minimum boiler temperature.
After the expiration of this time the text of the counter becomes green (1) and only then is
allowed to start measuring.
Technical instructions REGULATION PelTec / PelTec-lambda
- the minimum boiler temperature: min. 60°C
5.3. Chimney sweeper
1.
Chimney sweeper
2.
3.
120°C
O2=8%
30%
80°C
1700
15k
0%
Time
Power
00:00:00
60°C
Chimney sweeper
05:08
OFF
55
