Centrometal PelTec II Lambda 12-48 Technical Instructions

Centrometal PelTec II Lambda 12-48 Technical Instructions

Hot water boiler
Hide thumbs Also See for PelTec II Lambda 12-48:
Table of Contents

Advertisement

Quick Links

Download this manual
Centrometal d.o.o. - Glavna 12, 40306 Macinec, Croatia, tel: +385 40 372 600, fax: +385 40 372 611
ENG
for installation, use and maintenance
of hot water boiler and installation of
additional equipment
THE FIRST START-UP MUST BE DONE BY AUTHORIZED
PERSON, OTHERWISE PRODUCT WARRANTY IS NOT
VALID.
TU-PLTII-12-48-7-2024-ENG
H E A T I N G T E C H N I Q U E
H E A T I N G T E C H N I Q U E
TECHNICAL INSTRUCTIONS
You can find the latest technical instructions
for PelTec II Lambda by scanning the
QR code or at the web address:
https://www.centrometal.hr/en/portfolio/peltec-ii-lambda-eng/
PelTec II Lambda 12-48
BOOK 1/2
