2. Chlorinator OFF, High Salt/Amps

The message 'Chlorinator Off – High Salt/Amps' indicates that the ProLogic has
detected an amperage draw, from the turbo cell, that exceeds the allowable threshold
Test salt level
Step 2A
Desired Salt
Concentration:
3200PPM
Test the salt concentration of the water using an
independent test, with a calibrated salt meter. IF salt is
above 3400, go directly to 2D. IF correct, go to 2B.
NOTE: If the main circulation pump was recently turned on, the chlorinator may show up to a 60
second Filter delay. Once the countdown expires, verify the voltage, amperage, temperature and
18
for the programmed cell model.
salt level are expressed under the 'Diagnostic Menu'.
Reset chlorinator in diagnostics
Step 2B
1
2
3
With the pump running, press the 'Menu' button until
'Diagnostic Menu' appears. Press the (>) one time. Then
press the (+) to reset the chlorinator and go to 2C.
