Chapter 2: Jumpers and Connectors

PCIe x16 Select

Connector type: 1x3 3-pin header
Connector location: JCFG1
1 3
Pin Settings
1-2 On 1(CFG1)
2-3 On 0
1-2 On: default
Pin Definition
1 VCCIO
2 CPU_CFG6_C
3 GND
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
PCIe x16 Select
Connector type: 1x3 3-pin header
Connector location: JCFG2
1 3
Pin Settings
1-2 On 1(CFG5)
2-3 On
1-2 On: default
Pin Definition
1 VCCIO
2 CPU_CFG5_C
3 GND
10
0
PEAK 888 User Manual
