Fueland its vaporsare extremelyflammable
and explosive. Fire or explosion can cause
severeburnsor death.
WHEN ADDING FUEL
* Turn power washer OFF and let it cool at least two (2) minutes
before removingfuel cap. Loosen cap slowly to relieve 3ressurein
tank.
* Fillfuel tank outdoors.
* DO NOToverfill tank. Allow spacefor fuel expansion.
* If fuel spills, wait until it evaporatesbefore starting engine.
* Keep fuel away from sparks, open flames, pilot lights, heat, and
other ignition sources.
* DO NOTlight a cigarette or smoke.
1. Clean area around fuel fill cap, remove cap.
2. Slowly add regular unleaded fuel to fuel tank. Be careful not
to overfill. Fill to bottom of filter screen, this will allow for fuel
expansion (Figure 6).
3. Install fuel cap and let any spilled fuel evaporate before
starting engine.
Figure 6 - Adding Fuel
iMPORTANT:DONOTsiphon standingwater for the water supply.
Use ONLYcold water (tess than I O0°F).Water supply must be
adequateto handle greater than 3.8 gallons per minute and no
less than 30 psi.
NOTE:
Usinga One Way Valve (vacuum breaker or checkvalve) at
pumpinlet can causepumpor inlet connectordamage.
* There MUST be at least ten feet of unrestricted garden hose
between the power washer inlet and any device, such as a
vacuum breakeror check valve.
* Damage to equipment resulting from failure to follow this
instruction will void warranty.
Figure 7 - Inspect Inlet Screen
.
Connectthe garden hose (not to exceed 50 feet in length)to
the water inlet (Figure8). Tighten by hand.
Figure8 - Connect GardenHose
CONNECT H OSE ANDWATER SUPPLY TO PUMP
NOTE:
DO NOTrun the pumpwithoutthe water supplyconnected
and turned on. Damageto equipment resulting from failure to
follow this instruction will voidwarranty.
NOTE:
Remove and discard the shippingcapfrom the pump'swater
inlet beforeattachinghose.
.
2.
Run water through your garden hose for 30 secondsto clean
out any debris.
Before connecting garden hose to water inlet, inspect inlet
screen (A) (Figure 7). Clean screen if it contains debris or
haveit replacedif damaged.DONOTrun powerwasher if inlet
screen is damaged.
Risk of eye injury.Spray can splash backor propel
.._4_ objects.
* Alwayswear safety goggleswhen using this equipment o r in
vicinityof equipment in use.
