Security Info - MAXINCOM MUC1004 Administrator's Manual

Limit Rate
Limit Hit

3.10.2 Security Info

Alert Settings, if the device is attacked, the system will notify users the alert via
call or E-mail. the attack modes include IP attack and Web Login.
Table 3.10.2a Description of Alert Settings Edit
Parameters
Http://www.maxincom.com
MUC1004/2008/2016 Administrator guide
The maximum packets can be handled per unit time.
eg:(IP:192.168.6.88/32 Protocol:UDP Rate:10/sec)means
maximum 10 UDP packets from 192.168.6.88 can be
handled per minute,and drop the redundant packets.
The maximum connections can be handled per unit time.
eg:(Port:8022 Protocol:TCP Hit:10/minute)means
maximum 10 TCP connections to port 8022 can be
handled per minute,the eleventh connection will be
refused directly.
Figure 3.10.2 Alert Settings
Figure 3.10.2a Alert Settings Edit
Description
96 / 112
