Unreachable: The trunk is unreachable.
Failed: Trunk registration failed.
FXO Trunk:
Status
Idle: The port is idle.
Busy: The port is in use.
Unavailable: The port hasn‟t connected to the PSTN line.
More detail message, please refer to the LED indication of front panel.
Parameters
Status Shows the registration status of Trunk channel, including
registered and unregistered.
Trunk Type Trunk mode will allow IP phone or IPPBX to register or trunk
mode to register to provider
Name It describes this VoIP channel for the ease of identification. Its
value is character string
SIP/IAX Choose the type of this trunk, SIP or IAX
Transfer This will be the transport method used by the trunk. The
Protocol options are UDP (default) or TCP or TLS.
User Name The number for this VoIP channel
Hostname/IP Hostname or IP Address of this VoIP channel
Address

3.4 Network Configuration

3.4.1 LAN Configuration

Http://www.maxincom.com
MUC1004/2008/2016 Administrator guide
Table 3.3.3 Trunk Status
Description
Figure 3.4.1 LAN Configuration
15 / 112
