Index Indicators
1 RUN
2 PWR
3 WAN,LAN
1~4,(5~8),
4
(9~16)
Http://www.maxincom.com
MUC1004/2008/2016 Administrator guide
Table 1-3-1 Description of Front view
Description
On: Starting
Off: Abnormal
Blinking every 0.5s: Normal status
On: Power on
Off: Power off
Green LED: indicates the Internet interface is in Link .
Yellow LED: ON is indicates 100MBps Ethernet port.
Red LED stands for FXO port
Orange LED indicates presence of a BRI port.
Green LED stands for FXS port
Red LED blinks: FXO port isn‟t connected to PSTN line.
Alternately blinks Red
incoming call.
Alternately blinks Red
call.
Alternately blinks Green
Alternately blinks Green
call.
Figure 1-3-4 Rear view of MUC1004
and Green: FXO port has an
and Green fast: FXO port is in a
and Red: FXS port is ringing.
and Red fast: FXS port is in a
