3.3 System Information

System information interface shows the basic information of status information,
mobile information and SIP information.
3.3.1 System Information
Parameters
MAC Address Displays the current MAC of the gateway, for example:
70-B3-D5-1B-3D-02
Network Current IP address and subnet mask of gateway
DNS Server Displays DNS server IP address in the same network with the
gateway
System Up Shows the time period of the device running. For
Time example, :1h : 20m : 24s
Traffic Calculates the net flow, including the total bytes of message
Statistics
received and sent。
Version info Shows the current firmware version
Http://www.maxincom.com
MUC1004/2008/2016 Administrator guide
Figure 3.3.1 system Information
Table 3.3.1 System Information
Description
13 / 112
