MAXINCOM MUC1004 Administrator's Manual page 27

Table 3.5.1c Description of GSM Trunk
Parameters
Port
Trunk Name
Mobile Number
CLIR
Rx Gain
Tx Gain
Call Progress Tone
DTMF Detect Mode
DTMF Detect
Sensitive
PIN
Http://www.maxincom.com
MUC1004/2008/2016 Administrator guide
Figure 3.5.1b GSM Trunks
Figure 3.5.1c GSM Trunks Edit
A port for this trunk.
A name for this trunk.
Mobile number for this trunk.
Calling Line Identification Restriction.
The receive volume.
The transfer volume.
A ringback for this trunk.
Set default dtmfmode for detect DTMF.
Default: Echo Before
Echo Before: Detect DTMF before echocan.
Echo After: Detect DTMF after echocan.
DTMF detect sensitive.
The PIN is normally associated with the SIM card.
Description
27 / 112
