Table 3.4.1.2 Description of WAN Configuration
Parameter
Use WAN
Dynamic (DHCP)
Static IP Address
IP Address
Subnet Mask
Default Gateway
Primary DNS
Secondary DNS
PPPoE
User Name
Password

3.4.2 VLAN Configuration

A VLAN (Virtual LAN) is a logical local area network (or LAN) that extends
beyond a single traditional LAN to a group of LAN segments, given specific
configurations.
Http://www.maxincom.com
MUC1004/2008/2016 Administrator guide
Figure 3.4.1.2 WAN Configuration
Enalbe use wan
Enable the device obtain IP Address automatically
Configure the "IP Address", "Subnet Mask" and "Default
Gateway" by manual
Set the IP Address for PBX, It is recommended to
configure a static IP address for PBX
Set the subnet mask for PBX
Set the default gateway for PBX
Set the primary DNS Server for PBX.
Set the Secondary DNS Server for PBX.
Use PPPoE to
achieve IP address
PPPoE user name
PPPoE password
Description
