Chapter 1 - Web-Based Management - Transition Networks SM8TAT2SA Web User Manual

Chapter 1 - Web-based Management

Initial Configuration
This chapter describes how to configure and manage the SMxTAT2SA via the web user interface.
With this facility, you can easily access and monitor through any one port of the switch all the status
of the switch, including each port activity, Spanning tree status, port aggregation status, multicast
traffic, VLAN and priority status, even illegal access. SMxTAT2SA default values are:
After the SMxTAT2SA interface has been configured, you can browse it.
For instance, type http://192.168.1.77 in the address row in a browser; it will show the Login screen
and ask you for a username and password in order to login and access authentication.
The default Username is admin and default Password is admin. For first time use, enter the default
username and password, and then click the <Login> button. The login process now is complete. In
the login menu, you must enter the complete username and password respectively. The SMxTAT2SA
allows two or more users using administrator's identity to manage this switch; the administrator to
do the last setting will be the configuration to affect the system.
Note: When you login to the switch Web page to manage, type the Username admin and press
the <tab> key. Then type the Password admin and press Enter. When you login to the switch Web UI,
you can use IPv4 or IPv6 login to manage.
To optimize the display effect, we recommend Microsoft IE 6.0 above, Netscape V7.1 above or
Firefox V1.00 above with 1024x768 resolution. See the SMxTAT2SA Install Guide for Web browser
support.
Note: The SMxTAT2SA has the DHCP function enabled by default, so if you do not have a DHCP
server to provide an IP addresses to the switch, enter the default IP 192.168.1.77
33717 Rev. A
IP Address
192.168.1.77
Subnet Mask 255.255.255.0
Default Gateway
192.168.1.254
Username admin
Password
admin
https://www.transition.com Page 8 of 248
