Basic Guide
HITACHI SJ Series Inverter
Read this "Basic Guide", and keep it handy for future reference.
P1
Introduction
Contents
Chapter 1 Safety Instructions
Chapter 2 Installation and Wiring
Chapter 3 Operation Setting and Examples of I/O
Adjustment
Chapter 4 Settings
Chapter 5 Troubleshooting
Chapter 6 Maintenance and Inspection
Chapter 7 Specifications
Index
List of contact information
If you have any inquiry or problem,
Refer to Chapter 5 Troubleshooting
or
Contact to the Technical Inquiry Service
for Inverter found on the back cover.
When making a contact, inform
the reference number on below.
NT2511
