USING THE DTC LIBRARY

You can use the FixAdvisor to locate the
definition for a specified OBD2 DTC.
1. With the FixAdvisor in OBD2 mode, press
and release the M button.
The Main Menu displays.
2. Use the UP
necessary, to highlight DTC Library in the
Main Menu, then press the ENTER
button.
The Enter DTC screen displays. The
screen shows the code "P0001", with
the "P" highlighted.
3. Use the UP
necessary, to scroll to the desired DTC
type (P=Powertrain, U=Network, B=Body,
C=Chassis), then press the DTC/FF button.
The selected character displays "solid", and the next character is
highlighted.
4. Select the remaining characters in the DTC in the same way,
pressing the DTC/FF button to confirm each character. When you
have selected all the DTC characters, press the ENTER
to view the DTC definition.
If you entered a "Generic" DTC (DTCs that start with "P0", "P2"
and some "P3"):
- The
definition (if available) show on the
FixAdvisor's display.
If a definition for the DTC you entered
is not available, an advisory message
shows on the Scan Tool's display.
If you
Specific" DTC (DTCs that start with
"P1" and some "P3"):
- The "Select Manufacturer" screen
displays.
- Use the UP
buttons, as necessary, to highlight
the appropriate manufacturer, then
press the ENTER
display the correct DTC for your
vehicle. A confirmation message
shows on the LCD display.
MD70
and DOWN
and DOWN
selected DTC
entered a "Manufacturer-
and DOWN
Additional Tests
USING THE DTC LIBRARY
buttons, as
buttons, as
and DTC
button to
button
77
