3. With the right hand end of the ribbon tilted down, insert the tab on
the end of the cartridge into the opening in the ribbon tray.
Installing the Ribbon Cartridge
4. Now lower the left end of the cartridge down while guiding the
ribbon fabric between the nose of the print head and the ribbon guide
pins. Continue to lower the cartridge until the tab on the left end of
the cartridge snaps into place.
Ribbon Guided Between the Print Head
and Guide Pins
