- Page 1 PrintMaster 850 Series Operator’s Manual ©Printek, Inc. 2002 1517 Townline Road Benton Harbor, MI 49022 (800) 368-4636 www.printek.com Part Number 5164 Rev. C...
- Page 2 IBM, Proprinter, and IPDS are registered trademarks of International Business Machines Co.; DEC is a registered trademark of Digital Equipment Corporation; Epson is a registered trademark of Seiko Epson; Printek is a registered trademark of Printek, Inc.; Genicom is a registered trademark of Genicom Corporation;...
- Page 3 Do not operate near a heat source. No user-serviceable parts inside. Refer service or repairs to a qualified service professional. Use of genuine Printek replacement parts is required to warrant proper, safe operation. Any alteration or modification of this device voids the user warranty and may make the product unsafe to operate.
- Page 4 Enthält keine Teile, die vom Bediener instandgesetzt werden können. Bitte wenden Sie sich bei Instandsetzung oder Reparatur an qualifiziertes Kundendienstpersonal. Die Verwendung von echten Printek Ersatzteilen ist notwendig, um ordnungsgemäßen, sicheren Betrieb zu gewährleisten. Änderungen oder Modifikationen dieses Geräts machen die Garantie ungültig und können den sicheren Betrieb des Produkts gefährden.
-
Page 5: Table Of Contents
Getting Started Installation Interface Set Up RS232C Serial Interface Parallel Interface Ethernet 10/100 BaseT Installing The Ribbon Cartridge Why Use Only Printek Installing a New Ribbon Cartridge Loading Paper PrintMaster 850 Single Tractor Model PrintMaster 852 Printer Self-test Daily Operation... - Page 6 Form Construction and Layout Tips Form Construction Form Layout Considerations Maintenance and Troubleshooting Messages Additional Troubleshooting Tips Preventive Maintenance Obtaining Service Advanced Setup Features Security Menu Using Remote Setup Using the Optional Setup Module Printer Reset Conditions Control Code and Escape Sequence Summaries...
- Page 7 GENICOM 3840 AND 3410 Emulation ANSI X3.64 Emulation Epson FX Emulation IBM Proprinter Emulation LA-120 Emulation Simple TTY Emulation Printek Emulation ASCII Character Tables Specifications Glossary of Terms V I I...
-
Page 9: Introduction
INTRODUCTION Thank you for purchasing a Printek Printer. This printer has been designed to provide years of service handling your most demanding printing requirements. In addition, an easy to use front panel combined with the ability to store ten different form configurations makes handling multiple forms as simple as a button press for the operator. -
Page 10: Manual Contents
USING REMOTE SETUP parameters from a host computer. USING THE SETUP MODULE Module can be used to copy Setup parameters from one printer to another or be used to backup your printers’ settings. PRINTER RESET CONDITIONS after power up or reset. - Page 11 CONTROL CODE AND ESCAPE SEQUENCE SUMMARIES lists the commands supported for each printer emulation. ASCII CHARACTER TABLES show the characters for each character set. SPECIFICATIONS list the operating ranges and ratings of the printer. GLOSSARY OF TERMS provides definitions for terms used in this manual.
-
Page 12: Getting Started
Installation Before installation, a suitable site must be chosen. Suitable sites include offices, computer rooms, and most factory environments. Printek printers have been designed to be rugged, heavy-duty printers. As such, they will handle most harsh environments, but should not be placed in direct sunlight or in areas that will exceed the rated temperature, humidity, or power requirements. - Page 13 (open front lid to access). Now connect the computer cable(s) to the appropriate interface. Next, connect the power cord supplied with the printer to the printer and an appropriate power outlet. The pictures below show t h e location of the interface connectors on the rear panel of the printer.
-
Page 14: Interface Set Up
Ethernet Interface Connectors on rear of printer Interface Set Up Depending upon which interface is being used to connect the printer to the host computer, some set up may or may not be required. This is true of the standard parallel, serial, or Ethernet. -
Page 15: Ethernet 10/100Baset
S T A R T E D Ethernet 10/100BaseT This interface uses a standard RJ-45 connector and the default printer emulation is Epson. For a complete description of all the default settings for this interface, refer to page 49. For additional software installation and operational information, please refer to the Troy XCD Quick Install Manual shipped with the unit. -
Page 16: Installing The Ribbon Cartridge
The reason this is possible is that Printek brand ribbons are manufactured to much higher quality standards than those offered by other manufacturers. This provides not only longer print head life, but also longer ribbon life… 15 million characters as compared to only 5 million characters f rom some generic ribbons. - Page 17 G E T T I N G S T A R T E D Using inferior ribbons would be like using poor quality fuel in your automobile. Premature engine failure and poor performance leading up to the failure would be the best you could expect.
-
Page 18: Installing A New Ribbon Cartridge
Installing a New Ribbon Cartridge Open the ribbon lid at the front of the printer. The printer automatically positions the print head for ribbon loading by moving it away from the platen surface and centering it laterally within the compartment. - Page 19 Rotate ribbon to ‚, to slide ribbon into Printhead/Shield gap. Pull ribbon toward you to ƒ. Close lid and put printer ONLINE to Note: DO NOT take up the ribbon automatically tension the ribbon. slack or reposition noseshield after seating cassette.
-
Page 20: Loading Paper
PrintMaster 850/850si Single Tractor Model Loading the Form in the Tractors 1. Open the paper door (rear lid) of the printer. This will provide access to the tractors as shown below. 2. Open the tractor doors and remove the old form. - Page 21 LOAD/FEED button or the ONLINE button. The LOAD/FEED button will position the form for printing but will not place the printer on line. The ONLINE button will both position the form and place the printer on line.
-
Page 22: Printmaster
Lift the front of the printer up to access the tractors, as shown below. The printer will remain in this raised position. Open the tractor doors and remove the old form. - Page 23 Lock the tractor in place by returning the lever to the up position. 6. Close the bottom paper door and lower the front of the printer down until it latches in place. Selecting Which Form to Print With the printer off line, press the UNLOAD/CHANGE button until the desired form is displayed.
-
Page 24: Printer Self-Test
To stop or restart printing the test pattern, press the ONLINE button. 7. To take the printer out of the test mode, stop the test by pressing the ONLINE button. 8. Open the front lid and press the MENU button until the display reads TEST MENU. - Page 25 G E T T I N G S T A R T E D 11. Close the front lid and press the ONLINE button.
-
Page 27: Daily Operation
DAILY OPERATION Introduction This chapter describes how to use the “everyday” features of the PrintMaster 850 Series printer. The items covered are: Control Panel Features features of the printer’s control panel. Selecting and Loading Forms or forms into the tractors and how to inform the printer of which forms are “loaded”. -
Page 28: Control Panel Features
Control Panel Features The following picture shows the printer’s control panel. The control panel consists of a two-line LCD display, a status indicator LED, 6 push button switches or “buttons”, and an Audible Alarm. Each of these items is described below... - Page 29 The printer is on line and ready to print. The printer is in the process of going back on line. Typically occurs after a new form has been loaded while the printer is confirming which forms are loaded in the tractors.
-
Page 30: Exposed Buttons
OFF. This button also toggles the printer between the on line and off line state. When the printer is on line, it may be printing or may begin printing at any time. To stop the printing or prevent printing from starting, use this button to take the printer off line (see “ONLINE Status Indicator”) above. - Page 31 LOAD: Loads the form that is presently selected. If the selected form is already recognized as “loaded” in the tractors, the printer will advance the form to the print position. If the selected form is not currently considered to be loaded in the tractors...
- Page 32 “ Selecting and Loading Forms”. This button is used to set up the various operating parameters of the printer for forms, interfaces, etc. This button is not used on a daily basis. For more information see the chapter on “...
-
Page 33: Selecting And Loading Forms
Note: A form is not considered “loaded” by merely placing the form in the tractors. To prevent printing on the wrong form, the printer must be made aware of what form(s) are currently loaded. When a new form is placed in the tractors, the form must be “loaded”... -
Page 34: Selecting A Form Already Loaded In The Tractors
Selecting a Form Already Loaded in the Tractors To select a form that is already physically in the tractors, take the printer off line and press the UNLOAD/CHANGE button until that form is displayed (a form that is not considered to be loaded will flash bottom line of the display). -
Page 35: Ejecting And Tearing Off A Form
When most print jobs are complete, the printer will command the paper to be positioned at the top of the next form so that the printer is ready for the next job. This is, however, dependent solely upon how the programmer chose to write your particular application software. - Page 36 2. Pull the paper toward the front of the printer and toward one side of the printer as shown. 3. Place the printer back on line with the ONLINE button (indicator changes to green).
-
Page 37: Aligning Print
O P E R A T I O N Aligning Print When a new form is loaded into the printer for the first time, it may be necessary to adjust where printing begins. If the print position needs to be adjusted, the following discussion will describe how this is accomplished. - Page 38 To move the print vertically on the page, press the ALIGN/ITEM button and the display will change to the following. Down/Up 0.00” The UP/DOWN ARROW buttons will move the print up or down in 1/100 inch increments. Note again that the arrow will change according to the direction the print is to be moved from the normal print position.
-
Page 39: Common Error Conditions
12345 Common Error Conditions Whenever the printer detects an error condition, it will automatically go off line. User correctable errors are “flashed” on the display. These errors can typically be recovered without loss of data and are listed in this section of the manual. -
Page 40: No Paper To Load
Depending upon how the printer has been set up, the printer may start printing where it left off or it may start at the beginning of the page where the error occurred and reprint the entire page. -
Page 41: Ribbon Lid Open
D A I L Y O P E R A T I O N Ribbon Lid Open This error occurs when ONLINE has been pressed and the ribbon lid has been left open. Close the lid and press ONLINE again. Other Errors If other errors occur, it is possible that they may not be resolved without the aid of a factory trained service technician. -
Page 42: Printer Configuration
PRINTER CONFIGURATION Introduction To Setup The PrintMaster 850 Series printers feature simple, easy to use menus for setting the various operating parameters for the printer. The parameters available in these menus usually only need to be set one time, either when the printer is first installed or perhaps when a new form is to be used. -
Page 43: Entering Setup
Setup mode as a reminder to use the yellow labels. The buttons used for Setup are shown on the next page. Note that the menu system works on a “what you see is what you get”... -
Page 44: Using The Submenu Button
MENU, and the TEST MENU. Continue to press the MENU button to select the desired menu. The MENU button may be pressed at any time to select a different menu. Using the SUBMENU Button The SUBMENU button selects additional menus that are related to the selected menu. -
Page 45: Forms Menu
Not all of these forms require the same printer settings for things such as font, character size, line spacing, or form length. The PrintMaster 850 Series printers store up to ten complete sets of form parameters including the name of the form. - Page 46 This is often true if the job is to be run overnight or at a remote and perhaps unattended location. When a form’s tractor path is set to Bottom +Rear, the printer will automatically switch to the rear path when the bottom path is empty and continue printing until both paths are empty.
-
Page 47: Form Length
Lines Per Inch Possible Values: 6*, 8 This item sets the line pitch to 6 or 8 lines per inch (LPI). Form Length 1 … 66* … 227 Lines Possible Values: This item sets the form length in lines at the current line pitch (LPI). For example: for an eleven-inch form, enter 66 if you are using six lines per inch or 88 if you are using eight lines per inch. - Page 48 Possible Values: 0* … 226 Lines This item sets the bottom margin in lines. Setting a bottom margin will reduce the size of the printable area of the page by the number of lines set. When the bottom margin is reached, the remainder of the page will be skipped and printing will resume at the beginning of the next page (or top margin if one is set).
- Page 49 This item selects the default font to be used. Draft Speed Possible Values: Normal*, Fast This item selects whether the Draft Font ( be selected when the printer receives a “select draft font” command from Epson FX FD Euro (858) ML (850) FD, DF, Draft Speed...
- Page 50 the host computer. This will allow the Fast Draft font to be used with programs, which would not be able to otherwise. Impact Force Possible Values: Normal*, High This item may be used to select High Impact for improved printing on multipart forms that do not otherwise print well on the back copies.
- Page 51 Char Value 35 36 64 91 92 93 94 96 123 124 125 126 France Germany England £ Denmark $ @ Æ Ø Sweden ¤ Italy Spain PTS $ @ Japan Zero Style Possible Values: Normal*, Slashed This item selects whether the numeral zero is printed with or without a slash through it.
-
Page 52: Interface Menu
In addition to the standard parallel interface and the RS-232C serial interface, which are furnished with the printer, 10/100BaseT Ethernet may also be installed. The Setup items for each interface are described in one of the following sections. -
Page 53: Rs-232C Serial Interface Items
Emulation Possible Values: Epson*, IBM Proprinter, DEC LA120/LA210, TTY, Printek, ANSI X3.64, Genicom 3840, Genicom 3410 This item selects the emulation to be used whenever the serial port is active. Emulation should be set to match the type of printer your software supports. - Page 54 Possible Values: No*, Yes This item selects whether the smallest possible I/O buffer should be used. Setting this item to No will allow the printer to make maximum use of the I/O buffer (see “ Paper Out Fault buffer size). Setting this to Yes may decrease performance, but is useful when using the printer with operating systems that try to keep track of which page is currently being printed by the printer.
-
Page 55: Baud Rate
Baud Rate Possible Values: 110, 150, 300, 600, 1200, 2400, 4800, 9600* This item selects the baud rate for the serial interface. This must be set to match the baud rate setting on the host computer. Data Bits 8*, 7 Possible Values: This item selects the number of data bits in the serial character frame. - Page 56 Enables or disables the transmission of the XON and XOFF characters from the printer to the host to control data flow to the printer. XOFF will be sent whenever the printer goes offline or the serial buffer is full. XON will be sent when the printer is again ready to receive characters.
-
Page 57: Parallel/Lan Interface Items
ETX/ACK Handshaking Possible Values: Off*, On Enables or disables the ACK response to receipt of the ETX character. This handshake method is useful for conditions where there are long transmission line delays such as telephone lines, which may be routed through satellites. - Page 58 DEC LA120/LA210, TTY, Printek, ANSI X3.64, Genicom 3840, Genicom 3410 This item selects the emulation to be used whenever the parallel port is active. The emulation should be set to match the type of printer your software supports. LAN Setup Possible Values:...
-
Page 59: Subnet Mask
set to Static, the user sets the TCP/IP address, Subnet Mask and TCP/IP Gateway address as follows: IP Address Possible Values: 000.000.000.000 … 255.255.255.255 To set the TCP/IP address, use the SUBMENU key to select which digit group you wish to change, and then use the UP/DOWN ARROW keys to change the value. - Page 60 Possible Values: Off, On* This item enables or disables automatic Carriage Returns (CR) whenever a Line Feed (LF), Vertical Tab (VT), or Form Feed (FF) is received. Automatic Line Feed Possible Values: Off*, On This item enables or disables automatic Line Feeds (LF) when a Carriage Return (CR) is received.
-
Page 61: Options Menu
Setting this item to buffer (see “ Paper Out Fault size). Setting this to using the printer with operating systems that try to keep track of which page is currently being printed by the printer. Options Menu OPTIONS MENU contains items, which do not pertain only to a specific form or specific interface, but rather affect how the printer works under all conditions. -
Page 62: Paper Out
This item sets the additional distance the paper will advance when scrolling to the tear bar. This allows the printer to be placed under a slot in a counter and have the tear-off positioned at the counter surface. Leave the distance set to 0.00 Inches to disable this feature. - Page 63 (the printer assumes there is not a complete page available), when reverse paper motion is attempted within the last one inch of the form, or when a paper jam occurs.
- Page 64 Character to Ignore Possible Values: 0, ... 255* This allows a single 8-bit character to be discarded as it is received. This is useful when the host application is sending an unwanted control character, for example. Values are in decimal, with printable characters displayed to the left of the decimal value.
-
Page 65: Page Size
User Language Possible Values: English*, French, German This selects the front panel language that will be used by the printer's LCD screen. Press the UP/DOWN ARROW keys to change the selection. Note: If you change the selected language, you may find it difficult to... - Page 66 selected (0 to 28K bytes in 1K byte increments) should be set to accommodate the largest page expected, but not unnecessarily large since the larger this is set, the smaller the effective I/O buffer. The 8K-byte default setting should be large enough to hold most pages of text, but may not be large enough to hold more complex or graphic filled pages.
-
Page 67: Test Menu
After setting this value, close lid and press ONLINE to begin printing. After printing is completed, the value of this item will automatically return to No. Note that once printing begins, taking the printer off line for any reason (ONLINE button pressed, ribbon lid opened, or a paper fault) will cause printing to be aborted. -
Page 68: Form Construction And Layout Tips
FORM CONSTRUCTION AND LAYOUT TIPS Form Construction Although the PrintMaster 850 Series printers have been designed to handle difficult forms, you may come across a form that does not feed reliably or provide adequate print quality on all copies. One of the main causes of paper misfeeds is a form that is “tented”. Tenting is a tent-like bulge at the perforation when forms are unfolded from the box. -
Page 69: Form Layout Considerations
While the print alignment can be adjusted on the PrintMaster 850 Series printer to 1/100 of an inch, this is often too much to expect of the forms manufacturer. - Page 70 S P E C I F Y I N G F O R M S placed on the form, avoid using a dark color to form the preprinted lines and boxes. Use a lighter color, preferably other than a gray that will allow the printed characters to still be read if misalignment occurs.
-
Page 71: Maintenance And Troubleshooting
To restart the printer after a fatal error, press the ONLINE button. The printer will reset to the power-on state and any pending print data in the printer buffer is lost. -
Page 72: Additional Troubleshooting Tips
(at left tractor under the paper (rear) lid and at far left of carriage under the ribbon lid). Also, the various bearings used in the PrintMaster 850 Series printers should not require any lubrication. OBTAINING SERVICE If your PrintMaster 850 Series printer should require service, please contact the company where you purchased the printer. - Page 73 M A I N T E N A N C E A N D T R O U B L E S H O O T I N G and number of your nearest Printek Authorized Service Center or to arrange for factory service.
-
Page 74: Advanced Setup Features
Security Menu The SECURITY MENU is for Information System managers who want to be able to set up a printer and then “lock out” operator changes to the various menus. This method of security may be set independently for the Align Print, the Forms menu, the Interface menu, or the Options menu. - Page 75 This item selects whether values set using Align Print (see ALIGNING PRINT on page 29) can be edited or only viewed by the operator. Initialize will reset the Align Print values for all forms to zero. Forms Menu Possible Values: Edit Allowed, View Only, Initialize This item selects whether items in the viewed by the operator.
-
Page 76: Using Remote Setup
Remote Setup via Windows Application Printek provides a remote setup program for Windows 95, 98, 2000 and NT users. This provides a convenient method for graphically configuring the printer. Visit www.printek.com... - Page 77 The I/O interface to be used for remote setup must be configured appropriately to communicate with the host system, and printer must be placed in remote setup mode. This is done by sending a 3- byte escape sequence to the printer. This sequence is ESC ESC ; or hexadecimal 1B 1B 3B.
- Page 78 Remote Setup Line Definitions [BeginPrintekSetup] AlignPrint=FactoryDefaults Forms=FactoryDefaults Interfaces=FactoryDefaults Options=FactoryDefaults Security=FactoryDefaults [Form0] ... [Form9] MovePrintLeft=0.00 ... 9.99 MovePrintRight=0.00 ... 9.99 MovePrintUp=0.00 ... 9.99 MovePrintDown=0.00 ... 9.99 FormName="UPTO16CHARACTERS" Tractor Path=Rear, Bottom, Bottom=Rear (852si only) LinesPerInch=6,8 FormLength=1 ... 227 TopMargin=0 ... 226 BottomMargin=0 ... 226 CharactersPerInch=10,12,13.3,15,16.74,17.14,2 LeftMargin=0 ...
- Page 79 Emulation=ANSI_X3.64,Epson,IBM_Proprinter, DEC_LA120,TTY,Printek AutoCR=Off,On AutoLF=Off,On HostFFatTOF=No,Yes Characters=Control,Printable MinimumBuffer=No,Yes BaudRate=110,150,300,600,1200,2400, 4800,9600 DataBits=8,7 StopBits=1,2 Parity=None,Even,Odd BusyPolarity=Low,High DTR=Power,Online,Busy XON/XOFF=Off,On ETX/ACK=Off,On [ParallelInterface] Emulation=ANSI_X3.64,Epson,IBM_Proprinter, DEC_LA120,TTY,Printek AutoCR=Off,On AutoLF=Off,On HostFFatTOF=No,Yes Characters=Control,Printable MinimumBuffer=No,Yes [Options] MaxFormAllowed=0 ... 9 AutoScroll=Off,1 ... 15 PaperOutFault=BreakPage,ReprintPage,FinishPag PageSize=0K ... 28K TopOfBarcode+Off,On TopOfOversized=Off,On IngnoreCharacter=Off,On CharToIgnore=0 ... 255...
- Page 80 A D V A N C E D S E T U P F E A T U R E S AlignPrint=ViewOnly,EditAllowed FormsMenu=ViewOnly,EditAllowed InterfaceMenu=ViewOnly,EditAllowed OptionsMenu=ViewOnly,EditAllowed [EndPrintekSetup] Remote Setup Example File The following example will set up three forms. Before the forms are set up, “AlignPrint”...
- Page 81 A D V A N C E D S E T U P F E A T U R E S Font=Epson_FX_DF [Form2] MovePrintDown=0.25 FormName="REPORTS" LinesPerInch=8 FormLength=68 CharactersPerInch=12 [EndPrintekSetup]...
-
Page 82: Using The Optional Setup Module
Introduction The optional Setup Module is a small cartridge that plugs directly into the RS-232 Serial connector on the rear of any PrintMaster 850 Series printer. This module is used to store a second copy of the current Setup configuration of the printer. This may then be used to restore settings after a printer is serviced or to copy the same configuration settings to another printer. - Page 83 Setup Module. If the data are not an exact match, the printer will proceed with step 8. If the data in the printer and the data in the module are an exact match, installation is complete and the printer will complete its power up procedure.
- Page 84 If you wish to copy the Setup data to the printer from the Setup Module, press the LOAD button. message and will now be configured according to the information that was in the Setup Module. Copying Setup to Printer If you wish to copy the Setup data to the Setup Module from the printer, press the UNLOAD button.
- Page 85 Note: Setup modules for Printek FormsMaster 8000 Series printers and PrintMaster 850 Series printers are not interchangeable. Data backup will not take place if the modules are used on the wrong printer.
-
Page 86: Printer Reset Conditions
PRINTER RESET CONDITIONS The following list describes conditions that are assumed whenever power is applied to the printer, changes have been made in MENU, or a reset escape sequence is received (when the printer is operating in an emulation mode that supports such a sequence). -
Page 87: Control Code And Escape Sequence Summaries
CONTROL CODE AND ESCAPE SEQUENCE SUMMARIES GENICOM 3840 and 3410 Emulation ESC D ESC E ESC ESC n ESC H ESC J ESC K ESC L ESC P <graphics> ESC \ ESC [(p1);(p2)<SP>B ESC [(p1);(p2)<SP>G ESC [(p)` ESC [(p)a ESC [(p)d ESC [(p)e ESC [(p1);(p2)f ESC [(Ps)g... -
Page 88: Ansi X3.64 Emulation
ESC [(p1)t ESC [(p1);(p2);...(p22)u ESC [(p1);(p2);...(p12)v ESC [(p1);(p2)<SP>{ ESC [(p1);(p2);...(p12)} ESC ]6;4;(p3);(p4)ESC\ ESC c ANSI X3.64 Emulation ESC D ESC E ESC ESC n ESC H ESC J ESC K ESC L ESC [ n1 ; n2 SP G ESC [ n ` ESC [ n a ESC [ n d ESC [ n e... -
Page 89: Epson Fx Emulation
Partial Line Up Vertical Tab Set Vertical Tab Stop Bell Backspace Cancel Line Carriage Return Cancel Condensed Mode Deselect Printer Cancel Double-Wide Mode (one line) Delete Character Master Print Mode Select Cancel MSB Control Absolute Horizontal Tab m DPI Graphics Underline Mode Select 8 LPI Set Line Spacing to 7/72"... - Page 90 ESC = ESC > ESC @ ESC A n ESC B n1 n2 ... nx NUL ESC C NUL n ESC C n ESC D n1 n2 ... nx NUL ESC E ESC EM n ESC ESC n ESC F ESC G ESC H ESC I n...
-
Page 91: Ibm Proprinter Emulation
ESC N n ESC O ESC Q n ESC R ESC S n ESC SI ESC SO ESC T Vertical Tab Deselect Printer Bell Backspace Cancel Line Carriage Return Select 10 CPI Cancel Double-Wide Mode (one line) Underline Mode Select 8 LPI Set Line Spacing to 7/72"... -
Page 92: Emulation
Select Software Interface n Set Horizontal Tab Stop Set Vertical Tab Stop Control Sequence Introducer Absolute Horizontal Tab Relative Horizontal Tab Printer Identification Printer Identification Absolute Vertical Tab Relative Vertical Tab Clear Horizontal Tab Stop Clear Horizontal Tab Stop Clear Vertical Tab Stop... -
Page 93: Simple Tty Emulation
ESC [ n1 ; n2 ; ... nx v ESC [ n w ESC [ n z Simple TTY Emulation ESC ESC n Printek Emulation ESC # m n1 n2 data Clear All Horizontal Tab Stops Clear All Vertical Tab Stops Select Automatic Carriage Return... -
Page 94: Deselect Printer
Select Script Modes Set character Spacing Unidirectional Mode Set Top and Bottom Margins Set Vertical Tab Stops Double-Wide Mode Print Single Character Reverse Line Feed Underline Mode End of Text Form Feed Horizontal Tab Line Feed Vertical Tab Deselect Printer... -
Page 95: Ascii Character Tables
ASCII CHARACTER TABLES Epson FX Font Character Set... - Page 96 A S C I I C H A R A C T E R T A B L E S PC Font Character Set EBCDIC Font Character Set...
- Page 97 A S C I I C H A R A C T E R T A B L E S PC Latin 2 (Slavic) Font Character Set OCR-A Font Character Set...
- Page 98 A S C I I C H A R A C T E R T A B L E S OCR-B Font Character Set ML Euro (858)
- Page 99 A S C I I C H A R A C T E R T A B L E S ML (850)
-
Page 100: Specifications
SPECIFICATIONS OCR-A Font Character Set PRINT SPEEDS Text Modes Fast Draft Draft Fast Draft High Impact Draft High Impact Letter Quality Optical Quality Graphics Modes 8 Wire Graphics 8 Wire Fast Graphics 9 Wire Graphics 9 Wire Fast Graphics CHARACTER MATRIX Fast Draft 7x9 in 9x9 cell. - Page 101 6 lpi, 8 lpi, or programmable in 1/216th or 1/288th of an inch. * LINE LENGTH 8.5 inches. CONTROL CODE AND ESCAPE SEQUENCE EMULATIONS Genicom 3840 Genicom 3410 ANSI X3.64 Epson FX IBM Proprinter DEC LA-120 and LA-210 Simple TTY Printek Basic Bar Code PAPER HANDLING...
- Page 102 S P E C I F I C A T I O N S Rear feed or optional bottom feed; zero tear off distance; paper out/paper jam detection; fan fold, continuous forms, edged punched. Paper width: 2.5 to 8.5 inches. Paper Slew Rate: 6 inches per second rear feed, 6 or 12 inches per second bottom feed.
- Page 103 Unit automatically measures and sets operating parameters each time unit is powered on. MTBF 10,000 hours on electronics, 50% duty cycle. 100% duty cycle for “si” models. Print head life of 500,000,000 draft mode (or equivalent) characters. Printer life excluding print head of 1,000,000 pages.
- Page 104 Print Head: 500 million draft equivalent character life. One year limited warranty for defects in materials and/or workmanship. Limited print head warranty may be extended to a two years with the use of only Printek ENVIRONMENTAL SPECIFICATIONS Power requirements: 100-250 VAC, 50-60 Hz Autoswitching.
- Page 105 S P E C I F I C A T I O N S * May be emulation dependent. Specifications subject to change without notice.
-
Page 106: Glossary Of Terms
Characters-per-second. The line upon which the next character will be printed. The column on the current line where the next character will be printed. Value or configuration that is assumed when the printer is turned on or reset. Draft Font. - Page 107 0 through 9 and A through F. Generally refers to the connection between the printer and the host computer. May also be used in reference to the user interface at the control panel of the printer.
- Page 108 1 0 0 Base eight numbering system. Digits are represented by the characters 0 through 7. Refers to the state of the printer when the ONLINE indicator is not solid green and the printer does not respond to the host computer.
