G E T T I N G S T A R T E D

Ethernet 10BaseT

This interface uses a standard RJ-45 connector and the default printer
emulation is Epson. For a complete description of all the default settings
for this interface, refer to page 57. For additional software installation and
operational information, please refer to the Axis manuals shipped with the
unit (disregard the Axis physical installation information).
Coax/Twinax Interface
This interface automatically sets itself for either Coax Mode or Twinax
Mode depending upon which adapter cable (coax BNC or twinax smart
"T") is attached to the 15 pin "D" connector when the printer is powered
on. Only the choices for the detected mode are available in the Setup
menus.
For Coax Mode, the default emulation is for a 3287 printer. For a complete
description of all the default settings for the Coax interface, refer to page 59.
For Twinax Mode, the default emulation is for a 4214 printer. For a
complete description of all the default settings for the Twinax interface, refer
to page 63.
IPDS Coax Interface
This interface uses a coax BNC adapter connected to the 15 pin "D"
connector on the rear of the printer. The default values should work in most
cases. For a complete description of all the default settings for this interface,
refer to page 67.
IPDS Twinax Interface
This interface uses a twinax smart "T" adapter connected to the 15 pin "D"
connector on the rear of the printer. The default values should work in most
cases. For a complete description of all the default settings for this interface,
refer to page 72.
7
