Maintenance Manual of 4M11 Series Diesel Engine For Land Power Generators
the oil inlet pipe subassembly. Rotate the turbocharger impeller to determine
whether it rotates freely without jamming.
7. Assemble the return pipe and pipe clamp of the turbocharger, and tighten them.
Note that the two pipe clamps shall be in the same direction and adjust the
position of return oil pipe;
8. Assemble and tighten the gasket and clamps and assemble the guard caps on two
ends.
9. 9. All gaskets can be used only once. Replace with new ones in event of repair.
85
