Maintenance Manual of 4M11 Series Diesel Engine For Land Power Generators
4.11

Vehicles Accessories System

4.11.1 Disassembly, Inspection, Repair, and Assembly of Alternator

4.11.1.1 Exploded View for Assembly of Alternator
4.11.1.2 Starter Disassembly Procedures
①Disassemble the alternator mounting bracket and connecting bolts and nuts of tension bolts
and take out the nuts, tension bolts, and tension bolt pads.
②Disassemble the other fastening bolt of alternator, rotate the alternator body to take out the
front belt of alternator, and take out the fastening bolt and alternator.
4.11.1.3 Inspection and Maintenance of Alternator
①Procedure for judgment of alternator malfunction
During the warranty service for the user, firstly test on the vehicle to judge whether the
alternator is malfunctioned. Tool: Test lamp. The procedure is shown in Figure4-66.
Figure 4-72 Exploded View for Assembly of Alternator
Alternator
Alternator
bracket
104
