4 . 1 8 . 2 P
4 . 1 8 . 2 P
Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
r o f i l e
r o f i l e
This page will show general information, such as name, group, IP address, MAC address,
model and password of VigorSwitch only when it connects to Vigor3900 series. By clicking
the edit button, a profile setting page for that switch will be shown. Note that each profile
represents one VigorSwitch.
Each item will be explained as follows:
Item
Enable Switch
Management
Refresh
Auto Refresh
Switch List
Description
Check the box to enable switch management.
Renew current web page.
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Status – Green icon means the VigorSwitch does connect to
Vigor3900 and is managed by Vigor3900. Grey icon means
Vigor3900 is detecting such VigorSwitch still. Red icon
means Vigor3900 cannot access it to get status information
for accessing password configuration of VigorSwitch is
wrong or Telnet service is disabled.
Switch Name – Display the name of VigorSwitch.
Group – Display the name of the group.
IP Address – Display the IP address link of VigorSwitch.
You can click the link to access into the web user interface
of VigorSwitch.
Mac Address – Display the MAC address of VigorSwitch.
Model – Display the model name of VigorSwitch.
Account - It is used to change the password for accessing
into VigorSwitch.
Edit – It is used to change general settings for the selected
VigorSwitch.
Del – It is used to remove the profiles for the selected
491
