Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
i
m
e
a
n
d
D
a
t
e
i
m
e
a
n
d
D
a
t
e
This page allows you to specify where the time of the router should be inquired from.
As an NTP (Network Time Protocol) client, the router gets standard time from the time
server. Some time-based functions cannot work properly until the system time functions run
successfully. Typically, NTP achieves high accuracy and reliability with multiple redundant
servers and diverse network paths.
Available parameters are listed as follows:
Item
Current System Time
Time Type
Server
Port
Interval
Time Zone
Daylight Saving
Apply
Cancel
Enter all of the settings and click Apply.
Description
Click Inquire Time to get the current time.
NTP – Select to inquire time information from Time Server
on the Internet using assigned protocol.
Browser - Select this option to use the browser time from
the remote administrator PC host as router's system time.
Type the domain name of the server.
Type the port number for the time server.
Select a time interval for updating from the NTP server.
Select the time zone where the router is located.
Click Enable to enable the daylight saving. Such feature is
available for certain area.
Click this button to save the configuration and exit the web
page.
Click it to discard the settings configured in this page.
423
