Each item will be explained as follows:
Item
Refresh
VLAN ID
Member
Untag
4 4 . . 1 1 . . 3 3 . . 2 2 M M i i r r r r o o r r C C o o n n f f i i g g
The administrator can monitor all the packets passing through mirrored port with the
mirroring port. It is useful for the administrator to analyze the troubles on Network.
Available parameters are listed as follows:
Item
Enable This Profile
Mirroring Port
Description
Click it to reload this page.
Display the VLAN ID number.
Display number of the WAN interface for the packets
tagged with such VLAN ID number to pass through.
Display number of the WAN interface for the VLAN ID
will be untagged for packets passing through the WAN
interface selected.
u u r r a a t t i i o o n n
Description
Check the box to enable the Mirror function for the switch.
Select a port for the administrator to use for viewing traffic
sent from mirrored ports.
