3. Click Add.
4. The following dialog appears.
Available parameters are listed as follows:
Item
Profile
IP Address
MAC
Comment
Apply
Cancel
5. Enter all the settings and click Apply.
6. A new profile has been added onto Bind Table.
Description
Type the name of the profile.
Type the IP address that will be used for the specified MAC
address.
Type the MAC address that is used to bind with the assigned
IP address.
Type a brief description for such profile.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
139
