Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Item
Start Time
End Time
Rest Time
Auth Type
LDAP Group
Logout/Clear
4 . 7 . 1 . 2 G e n e r a l S e t u
4 . 7 . 1 . 2 G e n e r a l S e t u
This page configures the main settings of web portal function.
Available parameters will be explained as follows:
Item
Web Portal
Use LAN DNS
Login Mode
Authentication Type
Description
log-in user.
Display the starting time of the network connection.
Display the ending time of the network connection.
Display the rest time of the network connection.
Display the authentication type (local, RADIUS, LDAP,
Login Disable, Guest) used by such user.
Display the LDAP group used by such user.
It is a button which is used to disconnect the connection
manually.
p
p
Description
Click Enable to enable such function.
Choose one of the LAN DNS profile
There are several login modes offered here for you to
choose.
Non Auth – Authentication is not required.
HTTP/HTTPS- If you choose such mode, the user can
access into Vigor router by HTTP or HTTPS.
This option is available when the Login Mode is set as
HTTP or HTTPS. Note that the authentication sequence
adopted by the system will be Local first, Guest second,
RADIUS third and LDAP the last. However, if you check
SMS, the router will authenticate the user with SMS rules
269
