4 4 . . 1 1 . . 3 3 . . 3 3 I I n n t t e e r r f f a a c c e e C C o o n n
This page allows you to modify the status (enable / disable), duplex (Half/Full), speed, flow
control and 802.3az for the WAN ports respectively.
Each item will be explained as follows:
Item
Edit
f f i i g g u u r r a a t t i i o o n n
Description
Choose the interface listed below and click the Edit button
to modify the settings. A pop up window will appear for you
to change the settings.
Interface – Display the name of WAN interface.
Enable – Check it to enable such interface.
Speed – Use the drop down list to specify the transmission
rate (Auto, 10M, 100M or 1000M) for such interface.
Flow Control – The default setting is Disable. If Enabled is
clicked, Vigor router will drop the packet if too much to
handle.
802.3az – It is a function of energy-efficient Ethernet.
111
