Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Item
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new File Extension Object profile has been created.
P P O b j e c t
P P O b j e c t
The IM, P2P, Protocol and Others types can be integrated as an APP object which can be
used in Firewall to block certain applications.
Each item will be explained as follows:
Item
APP Signature Upgrade
APP Support List
Add
Edit
Delete
Description
Click it to save the configuration.
Click it to exit the dialog without saving the configuration.
Description
Click it to open System Maintenance>>APP Signature
Upgrade configuration page.
APP Support List will display all of the applications with
versions supported by Vigor router. They are separated with
types of IM, P2P, Protocol and Others. Each tab will bring
out different items with supported versions.
Below shows the items with versions which are categorized
under IM.
Add a new profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Remove the selected profile.
To delete a rule, simply select the one you want to delete and
243
