4 . 4 . 2 D M
4 . 4 . 2 D M
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Use IP Alias
Port
Real Server
Apply
Cancel
4. Enter all of the settings and click Apply.
5. A new profile has been added onto server load balance table.
Z H o s t
Z H o s t
In computer networks, a DMZ (De-Militarized Zone) is a computer host or small network
inserted as a neutral zone between a company's private network and the outside public
network. It prevents outside users from getting direct access to company network. A DMZ is
an optional and more secure approach to a firewall and effectively acts as a proxy server as
well. In a typical DMZ configuration for a small company, a separate computer (or host in
network terms) receives requests from users within the private network for access to Web
sites or other companies accessible on the public network. The DMZ host then initializes
sessions for these requests on the public networks. However, the DMZ host is not able to
initiate a session back into the private network. It can only forward packets that have already
been requested. Users of the public network outside the company can access only the DMZ
host. The DMZ may typically also have the company's Web pages so these could be
served to the outside world. If an outside user penetrated the DMZ host's security, only the
Web pages will be corrupted but other company information would not be exposed.
Click Enable to specify IP alias for such profile.
Alias - WAN IP alias that can be selected and used for port
redirection. Before using it, please go to WAN>>General
Setup and enable the wan1 profile. Add several IP addresses
under Static mode for wan1.
Type a public port number for WAN interface.
Type the IP, port and weight values for the server(s) which is
installed behind Vigor router.
IP – Type the IP address (LAN subnet) of real server.
Port – Type a private port number for real server.
Weight – Greater value can be specified for a server with
high process capability.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
186 Vigor3900 Series User's Guide
