To enable the Central Management AP feature, the first thing you have to do is enabling port
settings. Click AP Management>>General Setup to get the following page.
Available parameters are listed as follows:
Item
AP Management
HTTP Allow
HTTP Port
HTTPS Allow
HTTPS Port
Username
Password
Polling Status
Polling Interval
Apply
Description
Check Enable to enable the settings configured in this page.
Click Enable to active the HTTP setting.
Type a port number for HTTP. The default value is 9080.
Click Enable to activate the HTTPS setting.
Type a port number for HTTPS. The default value is 9443.
Type a username which will be used by any Access Point
trying to connect to Vigor router.
Type a password which will be used by any Access Point
tried to connect to Vigor router.
Click Enable to activate polling interval setting.
Type the time value (unit is second). The range is from 60 ~
86400.
Click it to save the configuration.
