4 . 1 7 . 2 D
4 . 1 7 . 2 D
4 . 1 7 . 3 S
4 . 1 7 . 3 S
Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
a s h b o a r d
a s h b o a r d
This page shows VigorAP's information about Event Log, Total Traffic or Station
Number by displaying text and histogram.
t a t u s
t a t u s
This page displays general information for the VigorAP managed by Vigor3900.
Available parameters are listed as follows:
Item

Status

Device Name
IP Address
SSID
Description
Display current status (connected or disconnected) of the
managed AP.
The name of the AP managed by Vigor router will be
displayed here.
Display the true IP address of the access point.
Display the SSID configured for the access point(s)
471
