4 . 1 1 . 2 S
4 . 1 1 . 2 S
Vigor3900 Series User's Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Refresh
Profile Number Limit
Profile
URL
Host IP Address
H o w t o c r e a t e a n e w
H o w t o c r e a t e a n e w
1. Open SSL Proxy >> SSL Web Proxy.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
URL
Host IP Address
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new SSL Web Proxy profile has been created.
S L A p p l i c a t i o n
S L A p p l i c a t i o n
It provides a secure and flexible solution for network resources, including VNC (Virtual
Network Computer) /RDP (Remote Desktop Protocol), to any remote user with access to
Internet and a web browser.
4 4 . . 1 1 1 1 . . 2 2 . . 1 1 V V N N C C
VNC stands for Virtual Network Computing. It allows you to access and control a remote
PC through VNC protocol.
Renew current web page.
Display the total number (30) of the profiles to be created.
Display the name of the profile that you create.
Display the URL.
Display the IP address for the Host.
S S L W e b P r o x y
S S L W e b P r o x y
Description
Type name of the profile.
Type the address (function variation or IP address) or path
of the proxy server.
If you type function variation as URL, you have to type
corresponding IP address in this filed. Such field must
match with URL setting.
Click it to save the configuration.
Click it to exit the page without saving the configuration.
379
