3 Components and Power Supply
USB
Wi-Fi
LAN Switch
Eth WAN
Cell
Coverage
6
Tricolor
Bicolor
Tricolor
Tricolor
Tricolor
Monochrome Blue
Green -> interface up (blinking, in
some cards, when there is connection
data activity).
Off -> system stopped.
Red -> interface is unavailable be-
cause it is installing, it is not enabled
(shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not registered
in the network or the quality is in-
sufficient.
• Slow blinking. GSM connection
(GPRS).
• Steady. WCDMA (UMTS / HSDPA)
connection.
Blinking (green/red) -> activity/
maintenance.
Red -> interface down.
Green -> interface up.
Blinking (green/red) -> activity/
maintenance.
Green -> connected. Blinking: con-
nection data activity.
Red -> disconnected.
Green -> connected. Blinking: con-
nection data activity.
Amber -> blinking: auto-test.
Red -> disconnected.
Off -> system stopped.
Red -> interface is unavailable be-
cause it is installing, it's not enabled
(shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not registered
in the network or the quality is in-
sufficient.
• Slow blinking. GSM connection
(GPRS).
• Steady. WCDMA (UMTS / HSDPA)
connection.
Green -> connected. Blinking: con-
nection data activity.
Indicates the coverage level the in-
ternal 3G module has. Level from 0
