# After the port is re-enabled, delete several secure MAC addresses.
[Device] undo port-security mac-address security sticky 0002-0000-0015 vlan 1
[Device] undo port-security mac-address security sticky 0002-0000-0014 vlan 1
# Verify that the port security mode of the port changes to autoLearn, and the port can learn MAC
addresses again. (Details not shown.)

userLoginWithOUI configuration example

Network requirements
As shown in
device authenticates the client with a RADIUS server. If the authentication succeeds, the client is
authorized to access the Internet.
•
The RADIUS server at 192.168.1.2 functions as the primary authentication server and the
secondary accounting server. The RADIUS server at 192.168.1.3 functions as the secondary
authentication server and the primary accounting server. The shared key for authentication is
name, and the shared key for accounting is money.
•
All users use the authentication, authorization, and accounting methods of ISP domain sun.
•
The RADIUS server response timeout time is 5 seconds. The maximum number of RADIUS
packet retransmission attempts is five. The device sends real-time accounting packets to the
RADIUS server at 15-minute intervals, and sends usernames without domain names to the
RADIUS server.
Configure port GigabitEthernet 1/0/1 of the device to allow only one 802.1X user and a user who
uses one of the specified OUI values to be authenticated.
Figure 72 Network diagram
Host
Configuration procedure
The following configuration steps cover some AAA/RADIUS configuration commands. For more
information about the commands, see Security Command Reference.
Make sure the host and the RADIUS server can reach each other.
1. Configure AAA:
# Configure a RADIUS scheme named radsun.
<Device> system-view
[Device] radius scheme radsun
[Device-radius-radsun] primary authentication 192.168.1.2
[Device-radius-radsun] primary accounting 192.168.1.3
[Device-radius-radsun] secondary authentication 192.168.1.3
[Device-radius-radsun] secondary accounting 192.168.1.2
[Device-radius-radsun] key authentication simple name
[Device-radius-radsun] key accounting simple money
Figure 72, a client is connected to the device through port GigabitEthernet 1/0/1. The
Authentication servers
(192.168.1.2/24
192.168.1.3/24)
GE1/0/1
Device
Internet
