Chapter 2: Jumpers and Connectors
Internal Connectors
SATA Connectors
Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: SATA1 and SATA2
1
7
Pin
Definition
1
GND
3
TXN0
5
RXN0
7
GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
TXP0
4
GND
6
RXP0
USB 2.0 Headers
Connector type: 2x5 10-pin header
Connector location: USB1 and USB2
2
10
1
Pin
Definition
1
USB_PWR
3
-A
5
+A
7
GND
19
Pin
Definition
2
USB_PWR
4
-B
6
+B
8
GND
10
DUMMY
NEX 650 User Manual
