Chapter 3: BIOS Setup

Serial Port 2 Configuration

This section is used to configure serial port 2.
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Advanced
Serial Port 2 Configuration
[Enabled]
Serial Port
Device Settings IO=2F8h; IRQ=3;
Serial Port Mode [RS232]
Version 2.17.1249. Copyright (C) 2017 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Serial Port Mode
Select this to change the serial port mode to RS232, RS422 or RS485.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.

Serial Port 3 Configuration

This section is used to configure serial port 3.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Serial Port
Enables or disables the serial port.
Serial Port Mode
Select this to change the serial port mode to RS232, RS422 or RS485.
36
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Advanced
Serial Port 3 Configuration
[Enabled]
Serial Port
Device Settings IO=3E8h; IRQ=6;
Serial Port Mode [RS232]
Version 2.17.1249. Copyright (C) 2017 American Megatrends, Inc.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
NEX 650 User Manual
