Chapter 2: Jumpers and Connectors

COM2 to COM6 Internal Serial Port Connectors

Connector type: 2x5 10-pin header
Connector location: COM3, COM4, COM5 and COM6
10
2
1 9
Pin Definition
1 DCD
3 TXD
5 GND
7 RTS
9 RI_F_VCC
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 RXD
4 DTR
6 DSR
8 CTS
10 NC

CPU and System FAN Connectors

Connector type: 1x4 4-pin Wafer
Connector location: CPU_FAN1, CHA_FAN1 and CHA_FAN2
1 4
Pin Definition
1 PWN
2 SENSE
3 VCC
4 GND
13
