Chapter 3: BIOS Setup
USB Configuration
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
USB Configuration
XHCI Mode [Disabled]
USB 2.0(EHCI) Support [Enabled]
USB EHCI debug [Disabled]
Version 2.17.1249. Copyright (C) 2017 American Megatrends, Inc.
USB 2.0(EHCI) Support
Enables or disables the Enhanced Host Controller Interface (USB 2.0), one
EHCI controller must always be enabled.
USB EHCI Debug
Enables or disables PCH EHCI debug capability.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.

PCI Express Configuration

Control the USB EHCI (USB 2.0)
functions. One EHCI
controller must always be
enabled.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PCI Express Port 0 to PCI Express Port 3
Enables or disables the PCI Express ports 0 to 3 on the chipset.
45
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCI Express Configuration
PCI Express Port 0 [Enabled]
PCI Express Port 1 [Enabled]
PCI Express Port 2 [Enabled]
PCI Express Port 3 [Enabled]
Version 2.17.1249. Copyright (C) 2017 American Megatrends, Inc.
Enable or Disable the PCI
Express Port 0 in the Chipset.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
