Chapter 2: Jumpers and Connectors
SATA Power Output Connector
Connector type: 1x4 4-pin Wafer
Connector location: SATA_PWR1
1
4
Pin
Definition
1
+12V
2
GND
3
GND
4
+5V
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Chassis Intrusion Pin Headers
Connector type: 1x2 2-pin header
Connector location: CI1 and CI2
1
2
Pin
Definition
1
Signal
2
GND
25
NEX 650 User Manual
