Chapter 2: Jumpers and Connectors

LVDS Connector

Connector type: 2x20 40-pin header
Connector location: LVDS1
1 39
2 40
Pin Definition
1 LCD_VCC
3 +3.3V
5 LDDC_DATA
7 LVDS_A_DATA0
9 LVDS_A_DATA1#
11 GND
13 LVDS_A_DATA2
15 LVDS_A_DATA3#
17 GND
19 LVDS_A_CLK
21 LVDS_B_DATA0#
23 GND
25 LVDS_B_DATA1
27 LVDS_B_DATA2#
29 DPLVDD_EN
31 LVDS_B_DATA3
33 LVDS_B_CLK#
35 GND
37 CON_LBKLT_CTL
39 LCD_BLT_VCC
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 LCD_VCC
4 LDDC_CLK
6 LVDS_A_DATA0#
8 GND
10 LVDS_A_DATA1
12 LVDS_A_DATA2#
14 GND
16 LVDS_A_DATA3
18 LVDS_A_CLK#
20 GND
22 LVDS_B_DATA0
24 LVDS_B_DATA1#
26 GND
28 LVDS_B_DATA2
30 LVDS_B_DATA3#
32 GND
34 LVDS_B_CLK
36 CON_LBKLT_EN
38 LCD_BLT_VCC
40 LCD_BLT_VCC

Digital Input/Output Pin Header

Connector type: 2x5 10-pin header
Connector location: JGPIO1
2 10
1 9
Pin Definition
1 SIO_GP24
3 SIO_GP25
5 SIO_GP26
7 SIO_GP27
9 JGPIO_PWR
23
Pin Definition
2 SIO_GP20
4 SIO_GP21
6 SIO_GP22
8 SIO_GP23
10 GND
