Chapter 3: BIOS Setup
NCT6106D HW Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Advanced
Pc Health Status
System temperature : +42.5 ºc
: +38 ºc
CPU temperature
SYS Fan Speed : N/A
CPU Fan Speed : N/A
VCORE : +0.840 V
: +3.392 V
+3.3V
+5V : +5.020 V
+12V : +12.000 V
Case Open Feature [Disabled]
Version 2.17.1249. Copyright (C) 2017 American Megatrends, Inc.
System Temperature
Detects and displays the current system temperature.
CPU Temperature
Detects and displays the current CPU temperature.
SYS Fan Speed
Detects and displays the current system fan speed.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
CPU Fan Speed
Detects and displays the current CPU fan speed.
VCORE
Detects and displays the Vcore CPU voltage.
+3.3V
Detects and displays the 3.3V voltage.
+5V
Detects and displays the 5V voltage.
+12V
Detects and displays the 12V voltage.
→←: Select Screen
↑↓: Select Item
Case Open Feature
Enter: Select
+/-: Change Opt. Enables or disables the case open detection feature.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
