Teldat S.A.
3.5.3 Disconnecting
• Make sure that the device's power supply switch is in the OFF position (0).
• Disconnect the power supply from the mains.
• Disconnect the power supply from the device.
• Disconnect the data cables.
3.6 RST Button
The different features of the RST button are described below.
3.6.1 Rebooting the device
If you press the RST button once the device is running normally, it will restart.
3.6.2 Default Configuration
The RST button allows you to reboot the device to its factory default settings by following these steps:
• With the device switched off, press and hold down the RST button and switch on the router using the ON/OFF
switch (1).
• The PSU LED lights up (green) and the LED Slot starts blinking (amber). This blinking lasts 10 seconds.
• For the device to boot with the default settings, you must release the RST button while the LED Slot is blinking (i.e.
before 10 seconds have passed).
The router's default configuration establishes the following IP address and access mask:
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
Note
Some devices leave the factory with customized settings. This personalization can mean that
the default configuration is different from the one shown above.
3.7 Data connection
The Teldat Connect-104KF router has the following data connections:
3.7.1 4-port Ethernet Switch
The Teldat Connect-104KF router incorporates a 4-port 10/100/1000 BaseT Switch with automatic MDI/MDIX to
connect to a local area network (LAN).
Please pay careful attention to the labeling to avoid confusing the switch with other port types:
Fig. 8: LAN switch PORTs
Teldat Router Connect-104KF
3 Components and Power Supply
9
