Flowserve Logix 3400MD User Instructions page 30

Fieldbus Fieldbus Variable
Block Name
Index
83 VALVE_TRIMNO
84 VALVE_SN
85 STEM_DIAM
86 RATED_TRAVEL
87 INLET_PRESS
88 OUTLET_PRESS
89 ACT_MAN_ID
90 ACT_FAIL_ACTION
91 ACT_MODEL_NUM
92 ACT_SN
93 ACT_TYPE
94 ACT_SIZE
95 ACT_AREA
96 SPRING_TYPE
97 PO_DATE
98 INSTALL_DATE
71 VALVE_MODEL_NUM
99 MFG_PHONE
100 PUR_ORDER_NUM
102 XD_CAL_LOC
104 XD_CAL_WHO
Devide Mode and Status Parameters
13 DIAGNOSTICS_LEVEL
16 CONTROLLER_STATE_
STATUS
18 POSITIONER_STATUS
14 MECHANICAL_STATUS
30
Transducer Fieldbus
Block Datatypes
Register
XDTB_MAIN UNSIGNED 8 222
XDTB_MAIN VISIBLE_ 223
STRING
XDTB_MAIN FLOAT 224
XDTB_MAIN FLOAT 225
XDTB_MAIN FLOAT 226
XDTB_MAIN FLOAT 227
XDTB_MAIN UNSIGNED 8 228
XDTB_MAIN UNSIGNED 8 N/A
XDTB_MAIN VISIBLE_ N/A
STRING
XDTB_MAIN VISIBLE_ 231
STRING
XDTB_MAIN UNSIGNED 8 232
XDTB_MAIN UNSIGNED 8 233
XDTB_MAIN FLOAT 209
XDTB_MAIN UNSIGNED 8 234
XDTB_MAIN VISIBLE_ 235
STRING
XDTB_MAIN VISIBLE_ 236
STRING
XDTB_MAIN VISIBLE_ N/A
STRING
XDTB_MAIN VISIBLE_ N/A
STRING
XDTB_MAIN VISIBLE_ N/A
STRING
XDTB_MAIN VISIBLE_ N/A
STRING
XDTB_MAIN VISIBLE_ N/A
STRING
XDTB_MD UNSIGNED 8 258
XDTB_MAIN BIT_STRING 260
XDTB_MAIN BIT_STRING 261
XDTB_MD BIT_STRING 262
Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
Logix Positioner
Fix
Type Pt Variable Name
Rd
U_CHAR NO VALVEtrimno
STRING NO VALVEsn
FLOAT NO STEMdiam
FLOAT NO RATEDtrav
FLOAT NO INLETpress
FLOAT NO OUTLETpress
U_CHAR NO ACTman
N/A N/A N/A
N/A N/A N/A
U_CHAR NO ACTsn
U_CHAR NO ACTtype
U_CHAR NO ACTsize
U_INT /10 ACTarea
U_CHAR NO SPRINGtype
STRING NO PO_date
STRING NO INSTALL_date
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
N/A N/A N/A
U_CHAR NO LD_MD_MODE
U_CHAR NO Mode_Status
U_CHAR NO Positioner_
Status
U_CHAR NO Mechanical_
Status
R/W Description
NRW User Info, Valve, Trim Diameter
NRW User Info, Vlave, Serial Number
NRW User Info, Vlave, Stem/Shaft
Diameter
NRW User Info, Valve, Rated Travel
NRW User Info, Valve, Upstream
Pressure
NRW User Info, Valve, Downstream
Pressure
NRW User Info, Actuator,
Manufacturer
NRW For Future Use
NRW For Future Use
NRW User Info, Actuator Serial
Number
NRW User Info, Actuator, Type
NRW User Info, Actuator, Size
NRW Actuator Area
NRW User Info, Actuator, Spring
Type: single, dual, etc.
NRW User Info, Purchase Order Date
NRW User Info, Install Date
NRW User Info, Valve Model Number
NRW User Info, Manufacturer Phone
Number
NRW User Info, Purchase Order
Number
SRW User Info, Calibration Location
SRW User Info, Calibration done by
R Is this an LD or an MD Device
R Status, Alarm, Mode Flags
R Status, Alarm, Positioner Flags
R Status, Alarm, Mechanical Flags
