- Page 1 TECHNICAL BULLETIN Logix 3200IQ Digital Positioner FCD LGENTB0058-03 – 01/11 Experience In Motion...
- Page 3 The Logix 3200IQ offers valve status updates at a glance using (including burst mode) over previous versions of HART. the highly visible LEDs. Users can easily determine if a valve or Inside the Logix 3200MD Figure 1 –...
- Page 4 Internal diagnostic codes status and alarms without the need for a handheld communicator or laptop computer. With its unique Direct User Interface, the Logix 3200IQ positioner provides fast and easy configuration. Local Fast and simple configura- configuration switches allow the user to set all basic parameters for positioner operation, such as output charac- tion teristic (equal percent, linear or custom), air action, signal direction, gain, tuning, etc.
- Page 5 Logix 3200IQ Digital Positioner FCD LGENTB0058-03 – 01/11 Specifications Table 2 Table 5 Electrical Specifications Performance Specifications Power supply Two-wire, 4-20 mA input Response level ≤0.1% full scale Compliance voltage 10 VDC @ 20 mA Deadband ≤0.1% full scale Effective resistance 500 Ω...
- Page 6 This customized curve can be saved in the suite of tools and field device networks using the HART protocol and memory of the Logix 3200IQ, and either activated or overridden with provides access to the diagnostic information from field devices.
- Page 7 SoftTools, Signatures and Performance Testing Signatures Figure 2 – Ramp Open Test The Logix 3200IQ positioner is designed to assure that data is easily gathered, stored and compared to historical valve data so the user can determine the performance of critical valves.
- Page 8 Logix 3200IQ Digital Positioner FCD LGENTB0059-03 – 01/11 Dimensions NOTE: Dimensions in inches (mm) Supply, Output 1 and 10.63 Output 2 ports (269.92) ¼-18 NPT thread 4.05 5.92 (102.74) (150.24) 3.38 (85.83) 7.18 (182.45) 0.97 (24.69) Customer conduit ports ½-14 NPT thread 4.00...
- Page 9 Logix 3200IQ Digital Positioner FCD LGENTB0058-03 – 01/11 How to Order Selection Code Protocol HART Standard Diagnostics Advanced Aluminum, White Paint (Valtek) Stainless Steel, No Paint (Valtek) Aluminum, Black Paint (Automax) Material Aluminum, Food-Grade White Paint (Automax) Aluminum, Black Paint (Accord)
- Page 12 Flowserve Corporation has established industry leadership in the design and manufacture of its products. When properly selected, this Flowserve product is designed to perform its intended function safely during its useful life. However, the purchaser or user of Flowserve products should be aware that Flowserve products might be used in numerous applications under a wide variety of industrial service conditions.
