Meaning
Electronic Inability to Fail
YRRY
Safe
Pneumatic Inability to Fail
YRRR
Safe
YRGY
Friction Low Warning
YRGR
Pneumatic Leak Warning
YRYG
Friction High Warning
RGGY
Feedback Range Too Small
RGGY
Position Out of Range 0
RGGY
Position Out of Range 100
RGGR Inner Loop Offset Time Out
RGYG
Non Settle Time Out
RGYY
No Motion Time Out
RGRR Factory Reset State
Supply Pressure Low
RYYG
Alarm
RRGG Spool Sticking Alarm
RRGY
Friction Low Alarm
RRGR Friction High Alarm
RRYG
Piezo Voltage Error
RRYR
Hall Sensor Upper Position
RRYR
Hall Sensor Lower Position
Shunt Voltage Reference
RRRY
Error
RRRY
Watch Dog Time Out
RRRY
NV RAM Checksum Error
RRRG Loss of Inter PCB Comm
RRRR Position Deviation Alarm
*User Set
**Check Supply Pressure
***Circuit board problem. See IOM.

7.10 Version Number Checking

The version number of the embedded code may be checked at any time
except during a calibration by holding down the up arrow Jog button
( ). This will not alter the operation of the unit other than to change
the blink sequence to three blinks indicating the major version number.
18
Sticker Text
Electronic fail safe
39
23
warning
Pneumatic fail safe
17
24
warning
19
20
Friction low warning*
Pneumatic leak warning*
47
21
**
18
22
Friction high warning*
56
Feedback calibration
57
25
range alarm
58
Inner loop offset time out
61
26
alarm
Feedback non-settle time
60
27
out alarm
Feeback no motion time
59
28
out alarm**
Factory reset state.
1
29
Recalibrate
Supply pressure low
40
30
alarm* **
Pilot relay response
49
31
alarm*
21
32
Friction low alarm*
20
33
Friction high alarm*
35
34
Piezo voltage alarm***
52
Pilot relay position limit
35
alarm**
53
34
Electronics Error
36
36
alarm***
37
Loss of Board
38
27
Communication***
8
38
Position deviation alarm*
Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09

7.11 375 Handheld Communicator

The Logix 3400MD Quick Start Guide is available from a Flowserve
representative.
The Logix 3400MD digital positioner supports and is supported by the
375 Handheld Communicator. The Device Description (DD) files and the
manuals listed below can be obtained from the FF Foundation or from
your Flowserve representative. For more information please see the
following guides:
• Product Manual for the 375 Communicator.
• Logix 3400MD Digital Positioner Reference Manual.
Diagnostic features such as the signature tests and ramp tests are
performed internally. Certain calibration features such as actuator
pressure sensor calibrations are performed using the 375 Handheld
Communicator or using the Host software.

7.12 Device Description (DD) Files

The DD files for the Logix 3400 can be downloaded from the Flowserve
website, http://www.valvesight.com, or the Foundation Fieldbus
website, www.fieldbus.org.

7.13 Calibration

7.13.1 CALIBRATE_FLAGS

Position 0% Calibration Flag in CALIBRATE_FLAGS
During stroke calibration, the Logix 3400 digital positioner checks to
see if the linkage is placing the stem position sensor in range. If the
valve stroke causes stem position measurement to go out of range in
the closed position, a Position 0% Flag will be generated. The valve
stem will stop in the closed position and the red LED will blink. Linkage
must be adjusted to bring the sensor in range. Special LED indication:
If the linkage is out of range, the LEDs can be used as an adjustment
guide. The LED will change from a red to yellow when the linkage is
brought into range.
Position 100% Calibration Flag in CALIBRATE_FLAGS
During stroke calibration, the Logix 3400MD digital positioner checks
to see if the linkage is placing the stem position sensor in range. If the
valve stroke causes stem position measurement to go out of range in
the open position, a Position 100% Flag will be generated. The valve
stem will stop in the open position and the red LED will blink. Linkage
must be adjusted to bring the sensor in range. Special LED indication:
If the linkage is out of range, the LEDs can be used as an adjustment
guide. The LED will change from a red to yellow when the linkage is
brought into range.
