Flowserve Logix 3400MD User Instructions page 31

Fieldbus Fieldbus Variable
Block Name
Index
26 CALIBRATION_STATUS
13 ELECTRONIC_STATUS
21 PRESSURE_STATUS
15 INNERLOOP_STATUS
17 OUTERLOOP_STATUS
19 CONFIGURATION_STATUS
17 CONTROLLER_STATE_
MASK
19 POSITIONER_MASK
15 MECHANICAL_MASK
14 ELECTRONIC_MASK
22 PRESSURE_MASK
16 INNERLOOP_MASK
18 OUTERLOOP_MASK
20 CONFIGURATION_MASK
113 BLINK_CODE
Pro Mode Parameters
24 PST_TIME_BREAKAWAY
25 PST_PRESSURE_DIFF
26 PST_TIME_TO_TARGET
27 PST_RESULT
28 PST_TIME_LIMIT
29 ACTUATOR_RATIO
30 ACTUATION_RATIO_
HIGH_START_LIMIT
31 ACTUATION_RATIO_
HIGH_END_LIMIT
32 ACTUATION_RATIO_
PERCENT_YELLOW
50 SPOOL_RESPONSE_TIME
51 SPOOL_START_LIMIT
Transducer Fieldbus
Block Datatypes
Register
XDTB_MAIN BIT_STRING 263
XDTB_TECH BIT_STRING 264
XDTB_TECH BIT_STRING 265
XDTB_TECH BIT_STRING 266
XDTB_TECH BIT_STRING 267
XDTB_TECH BIT_STRING 269
XDTB_MAIN BIT_STRING 270
XDTB_MAIN BIT_STRING 271
XDTB_MD BIT_STRING 272
XDTB_TECH BIT_STRING 274
XDTB_TECH BIT_STRING 275
XDTB_TECH BIT_STRING 276
XDTB_TECH BIT_STRING 277
XDTB_TECH BIT_STRING 279
XDTB_MAIN UNSIGNED 8 283
XDTB_MD FLOAT 285
XDTB_MD FLOAT 286
XDTB_MD FLOAT 287
XDTB_MD UNSIGNED 8 288
XDTB_MD FLOAT 289
XDTB_MD FLOAT 290
XDTB_MD FLOAT 291
XDTB_MD FLOAT 292
XDTB_MD FLOAT 293
XDTB_MD FLOAT 295
XDTB_MD FLOAT 296
Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
Logix Positioner
Fix
Type Pt Variable Name
Rd
U_CHAR NO Calibration_
Status
U_CHAR NO Electronic_
Status
U_CHAR NO Pressure_Status
U_CHAR NO Inner
Loop_Status
U_CHAR NO Outer
Loop_Status
U_CHAR NO Configuration_
Status
U_CHAR NO Mode_Mask
U_CHAR NO Positioner_Mask
U_CHAR NO Mechanical_
Mask
U_CHAR NO Electronic_Mask
U_CHAR NO Pressure_Mask
U_CHAR NO Inner
Loop_Mask
U_CHAR NO Outer
Loop_Mask
U_CHAR NO Configuration_
Mask
U_CHAR NO Blink_Code
U_INT /100 PST_
TimeBreakaway
U_INT /100 PST_
PressureDiff
U_INT /100 PST_
TimeToTarget
U_CHAR NO PST_Result
U_INT /100 PST_TimeLimit
U_INT /100 Actuation_Ratio
U_INT /100 AR_HighStart
Limit
U_INT /100 AR_HighEnd
Limit
U_INT /100 AR_Percent
Yellow
U_INT NO Spool_Time_86
U_INT NO SS_LowLimit
R/W Description
R Status, Alarm, Calibration Flags
R Status, Alarm, Electronic Flags
R Status, Alarm, Pressure Flags
R Status, Alarm, Inner Loop Flags
R Status, Alarm, Outer Loop Flags
R Status, Alarm, Configuation
Flags
NRW Status, Alarm, Mode Flags
NRW Status, Alarm, Positioner Flags
NRW Status, Alarm, Mechanical Flags
NRW Status, Alarm, Electronic Flags
NRW Status, Alarm, Pressure Flags
NRW Status, Alarm, Inner Loop Flags
NRW Status, Alarm, Outer Loop Flags
NRW Status, Alarm, Configuration
Flags
R LED Status Blink Code
NR Partial Stroke Test breakaway
time
R Partial Stroke Test Pressure
Differential
NR Partial Stroke Test Time to
Target
R Partial Stroke Test Result (Pass
or Fail)
RW Partial Stroke Test Time Limit
RW Actuation Ratio In Percent
RW Actuation Ratio High Start Limit
RW Actuation Ratio High End Limit
NR Actuation Ration Percent Yellow
NR Spool Response Time
NRW Spool Start Limit
flowserve.com
31
