Triplett CamView IP Pro User Manual page 45

SYSTEM
Screen
Operation Method
Auto Power Off
Keyboard Tone
Software
POWER
Power Input
POE Injector
Battery
Power Output
Time
OTHER
Internal Storage
LED Light
Working Temperature
Working Humidity
Dimensions
Weight
CamView IP Pro, Pro-C, and Pro+ User Manual
4.0 inch TFT 800*RGB*480(WVGA) resolution, 16.7M color, backlight brightness adjust-
able
Power key, 12 control keys, QWERTY flip-open keyboard with 45 keys
Disable / 5~60 minutes
Enable / Disable
Supports online upgrades
POE source or POE injector (Green RJ45 port)
Input AC100~230V 50~60Hz, output 48V/15w
Dedicated battery, user replaceable, 7.4V lithium-ion polymer battery, capacity 22.2Wh
POE (802.3af, 802.3at) (Blue RJ45 port), DC12V 2A
Charging time 3~4 hours, max working time 10 hours
8GB flash
(2) 35lm LED lights
-10°C ~+55°C
30%~90%
190mm x 113mm x 37mm
1.6kg
41
